Protecting your home and business against surges
A complete protection adapted to your electrical network
Our Canadian made products
Warranty Details
Innovation
at your service
-
Protection at 10% of nominal voltage
-
Reactivity of a nanosecond
-
100 times longer connection time
-
Dissipates up to 20 times more heat
-
Compatibility with other protections and control systems
Discover Power Pressure ™ Innovation
Power pressure
The Galeos range
Complete protection adapted to your electrical network
Ask one of our representatives
Galeos series 2 (120 / 240V)
Voltage
120/240 V
Rated voltage (MCOV)
130/275 V
Phase
1 phase
Nominal discharge current (In)
20 kA
Single Pulse
20 kA
Protection mode
L-N, L-L
Galeos series 2+ (120 / 240V)
Voltage
120/240 V
Rated voltage (MCOV)
130/275 V
Phase
1 phase
Nominal discharge current (In)
20 kA
Single Pulse
20 kA
Protection mode
L-N, L-L, L-G, N-G
Galeos series 3 (120 / 208V)
Voltage
120/208 V
Rated voltage (MCOV)
130/275 V
Phase
3 phases
Nominal discharge current (In)
20 kA
Single Pulse
20 kA
Protection mode
L-N, L-L
Galeos series 4 (240V)
Voltage
240 V
Rated voltage (MCOV)
130/275 V
Phase
1 phase
Nominal discharge current (In)
20 kA
Single Pulse
20 kA
Protection mode
L-N, L-L, L-G, N-G
Galeos series 5 (227 / 480V)
Voltage
277/480 V
Rated voltage (MCOV)
320/550 V
Phase
3 phases
Nominal discharge current (In)
20 kA
Single Pulse
20 kA
Protection mode
L-N, L-L, L-G, N-G
Galeos series 6 (347 / 600V)
Voltage
347/600 V
Rated voltage (MCOV)
385/750 V
Phase
3 phases
Nominal discharge current (In)
20 kA
Single Pulse
20 kA
Protection mode
L-N, L-L, L-G, N-G
